- German-engineered Bosch Active Line electric drivetrain—the industry leader in electric bike technology
- 7-speed internal geared Shimano hub for versatility and low maintenance
- Hydraulic disc brakes for all-weather stopping power
- New frame design, with a reclining battery for a lower center of gravity and better ride
- Integrated Atlas Rack works seamlessly with Thule Yepp Maxi and Nexxt Maxi child seats—no adapters needed
- Resizes in seconds to fit riders 147 – 195 cm (4’10” – 6’5”) so a single bike can be shared by the family
Wheel Size20"
Speed7 Speed
Frame SizeOne Size
Max Weight105 kg (230 lb)
FrameVektron G2 Frame
ForkTern Tarsus, 6061-Al, hydroformed
StemTern Andros, adjustable, forged construction, patented technology
HeadsetTern Flux, cartridge bearings, Physis integrated
HandlebarsFlat bar, 6061-AL, Tern Andros adapted
Bar Tape/GripsVelo ergonomic, lock-on
SaddleTern Porter+, patented GripPad design, PrimeGel padding
Seat PostTern Telescope, 34.9 mm, Lite 2014-AL
Seat ClampOversize, 6061-AL, 2pc
SpokesStainless
RimsKinetix Comp, for disc
TyresSchwalbe Big Apple, 55-406, puncture protection, Reflex
ShiftersShimano Nexus, 7 spd
CranksetVektron custom, forged 6061-AL crankarm
Cassette16T
Bottom BracketMotor integrated
ChainDHT for eBike, GST corrosion resistant coating
PedalsMKS EZY
MotorBosch Active Line, 36 V/250 W, max speed 25 kph (EU); max speed 20 mph (US)
BatteryBosch PowerPack 400 Wh
Range400 Wh: 50-130 km (30-80 mi)
